B 13 B drill driver

Learn more

Side handle

The stable and large dimensioned side handle is 360° pivotable. This flexibility allows comfortable working to absorb high torques even at confined spaces . The adjustable side handle also simplifies work when drilling in series and overhead. The gummed surface of the side handle also ensures a safe grip.


Direct torque control

Depending on the wood-based material, it is possible that the tool may jam while working and thus subject the gearbox to enormous loads. The overload clutch reliably reduces these load peaks.

Applications & Features

Applications & Features

Applications

  • Installing screws, also large screws
  • Small and large drill holes (1st/2nd gear)
  • Working with hole saws and Forstner bits
  • Removing screws
  • Mixing and stirring viscous substances
  • Applications, requiring high torque (Drilling into stainless steel panels, threading with low torque, etc.)

Features

  • Very high torque in 1st gear (120 Nm)
  • High speed in 2nd gear
  • Speed infinitely adjustable with pushbutton switch
  • Clockwise/anticlockwise selector switch
  • Direct torque control (DTC) protects the mechanical components of the drill driver from being overloaded
  • High-strength magnesium gear housing
  • Robust, heavy-duty drill spindle mounting
  • 3-level reduced 2-speed gear
  • Robust large dimensioned side handle, pivotable about 360°, with a gummed surface for a safe grip
  • High quality keyless chuck for a rapid and easy tool change

Action

Handy and versatile with 120 Nm for appliactaion, requiring high torque

Installing large screws
Inclined screwing of long screws
Comfortable working in any situation

Technical data

B 13 B drill driver
Rated power 760 W
Machine weight 2.8 kg
Screws in softwood, without pre-drilling, max. 11 x 400 mm
Fixed torque (1st gear) 120 Nm
Drill spindle thread 1/2" - 20 UNF
Spindle collar dia. 43 mm
Chuck clamping range dia. 1,5 - 13 mm
Drilling dia. in softwood with Forstner bit 1st gear 51 - 80 mm
Drilling dia. in softwood with Forstner bit 2nd gear up to 50 mm
Rated speed 1st gear 0 - 170 rpm
Rated speed 2nd gear 0 - 1320 rpm

Video

Downloads

B 13 B operating instructions 0.6 MB
B 13 B spare part list 1 MB
B 13 B catalogue 0 MB
